Applications/Uses
- Suitable for coating applications, inks, wastewater, car wash liquids, solvents, chemicals, and dye transfer.
Specifications
| Model | ADP-0120 |
| Pressure Ratio |
1:1 |
| Max. Output Pressure | 7 bar |
| Max. Spray Flow | 20 L/min |
| Max. Suction Lift Level | 3.7 M |
| Max. Air Consumption | 340 Liter/per min |
| Max. Solids Convey | 1.0 mm |
| Temperature Range | 5-65 °C |
| Paint Inlet Size | 3/8“PT(F) |
| Paint Outlet Size | 1/2“PT(F) |
| Air Inlet Size | 1/4“PT(F) |
| Noise Level | 80 dB(A) |
| Diaphragm Material | UPE + Teflon |
| Size | L175 × W130 × H207 mm |
| Workplace Air Pressure Range | 0.5-7 bar |
| Pump Body (N.W.) | 4 kg |
| Pump Material | Aluminum Alloy |
| Package Weight(Standard) | 8 kg |
