Applications/Uses
- Suitable for primer and topcoat spraying on wood products, such as tabletops.
- Suitable for use in centralized paint circulation systems.
- Suitable for coating applications requiring finer atomization performance.
Specifications
| Model | APP-1514 |
| Pressure Ratio |
15:1 |
| Max. Spray Flow | 12.5 L/min |
| Volume/Cycle | 240 cc |
| Workplace Air Pressure Range | 3-6 bar |
| Air Motor Diameter | Ø152.4 mm |
| Air Inlet Size | 3/4“PT(F) |
| Paint Inlet Size | 1“PT(M) |
| Paint Outlet Size | 3/4“PT(M) |
| Pump Body (N.W.) | 94 kg |
| Wetted Parts | Stainless Steel / Teflon |
| Altemate throat Packing | Teflon |
| Piston Packing | Teflon |
