Applications/Uses
- Suitable for coating applications, inks, wastewater, car wash liquids, solvents, chemicals, and dye transfer.
Specifications
| Model | ADP-0145N |
| Pressure Ratio |
1:1 |
| Max. Output Pressure | 7 bar |
| Max. Spray Flow | 45 L/min |
| Max. Suction Lift Level | 5 M |
| Max. Air Consumption | 300 Liter/per min |
| Max. Solids Convey | 1.0 mm |
| Temperature Range | 5-65 °C |
| Paint Inlet Size | 3/4“PT(F) |
| Paint Outlet Size | 3/4“PT(F) |
| Air Inlet Size | 1/4“PT(F) |
| Noise Level | 80 dB(A) |
| Diaphragm Material | UPE + Teflon |
| Size | L208 × W175 × H274 mm |
| Workplace Air Pressure Range | 0.5-7 bar |
| Pump Body (N.W.) | 6 kg |
| Pump Material | Aluminum Alloy |
| Package Weight(Standard) | 11 kg |
