Applications/Uses
- Suitable for the transfer of coatings, resins, inks, and other low- to medium-viscosity fluids.
- Can be paired with a geared motor, brushless motor, or servo motor for high-precision metering and fluid delivery.
Specifications
| Specifications / Model |
K-PUMP-0.4 | K-PUMP-0.5 | K-PUMP-1.5 | K-PUMP-3 | K-PUMP-5 | |
| Displacement |
0.4 cc/rev | 0.5 cc/rev | 1.5 cc/rev | 3 cc/rev | 5 cc/rev | |
Pressure | Rated | 0.5 bar | 0.5 bar | 0.5 bar | 0.5 bar | 0.5 bar |
| Max. | 4 bar | 4 bar | 4 bar | 4 bar | 4 bar | |
Rotational Speed | Paint Supply | 20-100 rpm | 20-100 rpm | 20-100 rpm | 20-100 rpm | 20-100 rpm |
| Quick Cleaning | 150-200 rpm | 150-200 rpm | 150-200 rpm | 150-200 rpm | 150-200 rpm | |
Size | A | 2.3 mm | 2.85 mm | 8.5 mm | 17 mm | 28 mm |
| L | 127 mm | 128 mm | 133.5 mm | 142 mm | 153 mm | |
Paint Inlet/Outlet | Inlet | 3/8"PT | 3/8"PT | 3/8"PT | 3/8"PT | 3/8"PT |
| Outlet | 3/8"PT | 3/8"PT | 3/8"PT | 3/8"PT | 3/8"PT | |
| Net Weight | 1 kg | 1 kg | 1.2 kg | 1.4 kg | 1.65 kg | |
Accessories
| Name | Brushless Motor - Standard Type |
Brushless Motor - Electrostatic Type |
 |  | |
| Model | BMPF-S: For Ø6 mm gear pump shaft BMPF-L: For Ø12.7 mm gear pump shaft |
BMPF-S-HV: or Ø6 mm gear pump shaft BMPF-L-HV: For Ø12.7 mm gear pump shaft |
| Size | BMPF-S: L160 × W150 × H254 mm BMPF-L: L160 × W150 × H279 mm | BMPF-S-HV: L160 × W150 × H331 mm BMPF-L-HV: L160 × W150 × H354 mm |
